Circle:
The locus of the points at a certain distance from a fixed point is defined as a circle.
Chord:
A chord is a straight line that connects any two points on a circle.
A chord is represented by the letters \[\text{AB}\] .
If the longest chord passes through the centre of the circle, it is termed as the diameter.
The radius is twice as long as the diameter.
A diameter is referred to as a \[\text{CD}\].
A secant is a line that divides a circle in half.
\[\text{PQR}\] is a secant of a circle.
Circumference:
Circumference refers to the length of a full circle.
The circumference of a circle is defined as the border curve (or perimeter) of the circle.
Arc:
An arc is any section or a part of the circumference.
A diameter divides a circle into two equal pieces.
A minor arc is one that is smaller than a semicircle.
A major arc is one that is larger than a semicircle.
\[\overset\frown{\text{ADC}}\] is a minor arc, whereas \[\overset\frown{\text{ABC}}\] is a major arc.
Sector:
A sector is the area between an arc and the two radii that connect the arc's centre and end points.
A segment is a section of a circle that has been cut off by a chord.
Concentric Circles:
Concentric circles are circles with the same centre.
Theorem \[\text{1}\]:
A straight line drawn from the centre of a circle to bisect a chord which is not a diameter, is at right angles to the chord.
Given Data:
Here, \[\text{AB}\] is a chord of a circle with the centre \[\text{O}\].
The midpoint of \[\text{AB}\] is \[\text{M}\].
\[\text{OM}\] is joined.
To Prove:
\[\angle \text{AMO = }\angle \text{BMO = 9}{{\text{0}}^{\text{0}}}\]
Construction:
Join \[\text{AO}\] and \[\text{BO}\].
Proof:
In \[\Delta \text{AOM }\]and \[\Delta \text{BOM }\]
Theorem \[2\] (Converse of theorem \[1\]):
The perpendicular to a chord from the centre of a circle bisects the chord.
Given Data:
Here, \[\text{AB}\] is a chord of a circle with the centre \[\text{O}\].
\[\text{OM}\bot \text{AB}\]
To Prove:
\[\text{AM = BM}\]
Construction:
Join \[\text{AO}\] and \[\text{BO}\].
Proof:
In \[\Delta \text{AOM }\]and \[\Delta \text{BOM }\]
The transposition of a statement consisting of 'data' and 'to prove' is the converse of a theorem.
We can see how it works by looking at the previous two theorems:
Theorem \[3\]:
Equal chords of a circle are equidistant from the centre.
Given Data:
Here, \[\text{AB}\]and \[\text{CD}\]are equal chords of a circle with centre \[\text{O}\].
\[\text{OK}\bot \text{AB}\] and \[\text{OL}\bot \text{CD}\]
To Prove:
\[\text{OK = OL}\]
Construction:
Join \[\text{AO}\] and \[\text{CO}\].
Proof:
Theorem \[4\](Converse of theorem \[3\]):
Chords which are equidistant from the centre of a circle are equal.
Given Data:
Here, \[\text{AB}\]and \[\text{CD}\]are equal chords of a circle with centre \[\text{O}\].
\[\text{OK}\bot \text{AB}\] and \[\text{OL}\bot \text{CD}\]
\[\text{OK = OL}\]
To Prove:
\[\text{AB = CD}\]
Construction:
Join \[\text{AO}\] and \[\text{CO}\].
Proof:
In \[\Delta \text{AOK}\]and \[\Delta \text{COL }\]
Theorem \[5\]:
There is one circle, and only one, which passes through three given points not in a straight line.
Given Data:
Here, \[\text{X, Y}\]and \[\text{Z}\] are three points not in a straight line.
To Prove:
A unique circle passes through \[\text{X, Y}\]and \[\text{Z}\].
Construction:
Join \[\text{XY}\] and \[\text{YZ}\].
Draw perpendicular bisectors of \[\text{XY}\] and \[\text{YZ}\] to meet at \[\text{O}\].
Proof:
Angle Properties (Angle, Cyclic Quadrilaterals and Arcs):
In figure\[\left( \text{i} \right)\] , the straight line \[\text{AB}\]students \[\angle \text{APB}\] on the circumference.
\[\angle \text{APB}\]can be said to be subtended by arc \[\text{AMB}\], on the remaining part of the circumference.
In fig. \[\left( \text{ii} \right)\] , arc \[\text{AMB}\] subtends \[\angle \text{APB}\] on the circumference, and it subtends \[\angle \text{AOB}\] at the centre.
In fig. \[\left( \text{iii} \right)\], \[\angle \text{APB}\] and \[\angle \text{AQB}\] are in the same segment.
Now we will go through the theorems based on the angle properties of the circles.
Theorem \[6\]:
The angle at which an arc of a circle subtends at the centre is double the angle which it subtends at any point on the remaining part of the circumference.
Given Data:
Arc \[\text{AMB}\]subtends \[\square \text{AOB}\] at the center \[\text{O}\] of the circle and \[\square \text{APB}\] on the remaining part of circumference.
To Prove:
\[\angle \text{AOB = 2}\angle \text{APB}\]
Construction:
Join \[\text{PO}\] and produce it to \[\text{Q}\].
Let, \[\angle \text{APQ = x}\] and \[\angle \text{BPQ = y}\]
Proof:
Theorem \[7\]:
Angles in the same segment of a circle are equal.
Given Data:
\[\angle \text{APB}\] and \[\angle \text{AQB}\] are in the same segment of a circle with center \[\text{O}\].
To Prove:
\[\angle \text{APB = }\angle \text{AQB}\]
Construction:
Join \[\text{AO}\] and \[\text{BO}\].
Let arc \[\text{AMB}\]subtend angle \[\text{x}\] at the center \[\text{O}\].
Proof:
Theorem \[8\]:
The angle in a semicircle is a right angle.
Given Data:
\[\text{AB}\] is the diameter of a circle with center \[\text{O}\].
\[\text{P}\] is any point on the circle.
To Prove:
\[\angle \text{APB = }{{90}^{\circ }}\]
Proof:
Cyclic Quadrilaterals:
If the vertices of a quadrilateral lie on a circle, the quadrilateral is called a cyclic quadrilateral.
The vertices are known as concyclic points.
From the above figure, \[\text{ABCD}\] is a cyclic quadrilateral.
The vertices \[\text{A, B, C}\] and \[\text{D}\] are concyclic points.
Theorem \[9\]:
The opposite angles of a quadrilateral inscribed in a circle (cyclic) are supplementary.
Given Data:
\[\text{ABCD}\] is a cyclic quadrilateral.
\[\text{O}\] is the center of a circle.
To Prove:
\[\angle \text{A+}\angle \text{C = 18}{{0}^{\circ }}\]
\[\angle \text{B+}\angle \text{D = 18}{{0}^{\circ }}\]
Proof:
Corollary:
The exterior angle of a cyclic quadrilateral is equal to the interior opposite angle.
Given Data:
\[\text{ABCD}\] is a cyclic quadrilateral.
\[\text{BC}\] is produced to \[\text{E}\]
To Prove:
\[\angle \text{DCE}=\angle \text{A}\]
Proof:
Alternate Segment Property
Theorem \[10\]:
The angle between a tangent and a chord through the point of contact is equal to the angle in the alternate segment.
Given Data:
A straight line \[\text{SAT}\] touches a given circle with centre \[\text{O}\] at \[\text{A}\]. \[\text{AC}\] is a chord through the point of contact \[\text{A}\].
\[\angle \text{ADC}\] is an angle in the alternate segment to \[\angle \text{CAT}\] and \[\angle \text{AEC}\]is an angle in the alternate segment to \[\angle \text{CAS}\]
To Prove:
\[\angle \text{CAT}=\angle \text{ADC}\]
\[\angle \text{CAS}=\angle \text{AEC}\]
Construction:
Draw \[\text{AOB}\] as diameter and join \[\text{BC}\] and \[\text{OC}\].
Proof:
Theorem \[11\]:
In equal circles (or in the same circle), if two arcs subtend equal angles at the centres, they are equal.
Given Data:
\[\text{AXB}\] and \[\text{CYD}\] are equal circles with centers \[\text{P}\] and \[\text{O}\].
Arcs \[\text{AMD, CND}\] subtend equal angles \[\text{APB, CQD}\].
To Prove:
\[\text{arc AMD = arc CND}\]
Proof:
Theorem \[12\] (Converse of \[11\]):
In equal circles (or in the same circle) if two arcs are equal, they subtend equal angles at the centres.
Given Data:
In equal circles \[\text{AXB}\] and \[\text{CYD}\], equal arcs \[\text{AMD}\] and \[\text{CND}\] subtend \[\angle \text{APB}\] and \[\angle \text{CQD}\] at the centers \[\text{P}\] and \[\text{Q}\] respectively.
To Prove:
\[\angle \text{APB = }\angle \text{CQD}\]
Proof:
In case of the same circle:
Figures \[\left( \text{ii} \right)\] and \[\left( \text{iii} \right)\] can be considered to be two equal circles which are obtained from figure \[\left( \text{i} \right)\] and then the above proofs may be applied.
Theorem \[13\]):
In equal circles (or in the same circle), if two chords are equal, they cut off equal arcs.
Given Data:
In equal circles \[\text{AXB, CYD}\] with centers \[\text{P}\] and \[\text{Q}\] have
\[\text{chord AB = chord CD}\]
To Prove:
\[\text{arc AMB = arc CND}\]
\[\text{arc AXB = arc CYD}\]
Proof:
In \[\Delta \text{ABP}\] and \[\Delta \text{CDQ}\]
Theorem \[14\] (Converse of \[13\]):
In equal circles (or in the same circle) if two arcs are equal, the chords of the arcs are equal.
Given Data:
Equal circles \[\text{AXB, CYD}\] with centers \[\text{P}\] and \[\text{Q}\] have
\[\text{arc AMB = arc CND}\]
To Prove:
\[\text{chord AB = chord CD}\]
Construction:
Join \[\text{AP, BP, CQ}\] and \[\text{DQ}\].
Proof:
In \[\Delta \text{ABP}\] and \[\Delta \text{CDQ}\]
Theorem \[15\]:
If two chords of a circle intersect internally, then the product of the length of the segments are equal.
Given Data:
\[\text{AB}\] and \[\text{CD}\] are chords of a circle intersecting externally at \[\text{P}\].
To Prove:
\[\text{AP }\!\!\times\!\!\text{ BP = CP}\times \text{DP}\]
Construction:
Join \[\text{AC}\] and \[\text{BD}\].
Proof:
In \[\Delta \text{APC}\] and \[\Delta \text{DPB}\]
Theorem \[16\]:
If two chords of a circle intersect externally, then the product of the lengths of the segments are equal.
Given Data:
\[\text{AB}\] and \[\text{CD}\] are chords of a circle intersecting externally at \[\text{P}\].
To Prove:
\[\text{AP }\!\!\times\!\!\text{ BP = CP}\times \text{DP}\]
Construction:
Join \[\text{AC}\] and \[\text{BD}\].
Proof:
In \[\Delta \text{ACP}\] and \[\Delta \text{DBP}\]
Theorem \[17\]:
If a chord and a tangent intersect externally, then the product of the lengths of the segments of the chord is equal to the square on the length of the tangent from the point of contact to the point of intersection.
Given Data:
A chord \[\text{AB}\] and a tangent \[\text{TP}\] at a point \[\text{T}\] on the circle intersect at \[\text{P}\].
To Prove:
\[\text{AP }\!\!\times\!\!\text{ BP = P}{{\text{T}}^{\text{2}}}\]
Construction:
Join \[\text{AT}\] and \[\text{BT}\].
Proof:
Test for Concyclic Points:
Conversely, the statement, 'Angles in the same segment of a circle are equal', is one test for concyclic points.
We state:
If two equal angles are on the same side of a line and are subtended by it, then the four points are concyclic.
In the figure, if $\angle P=\angle Q$and the points $P,Q$ are on the same side of $AB$, then the points $A,B,P$ and $Q$are concyclic.
Converse of 'opposite angles of a cyclic quadrilateral are supplementary' is one more test for concyclic points.
We state:
If the opposite angles of a quadrilateral are supplementary, then its vertices are concyclic.
In the figure, if $\angle \text{A}+\angle C={{180}^{\circ }}$ then $\text{A, B, C}$ and $\text{D}$ are concyclic points.
Key Takeaways of NCERT Solutions Class 9 Maths Chapter 9 - Circles Free PDF
The circles class 9 questions with solutions allow the students to take several benefits. They are:
Students can score better marks and gain good knowledge.
These PDFs are available for free.
Students can take either a soft copy or hard copy.
Conclusion
NCERT Solutions for Class 9 Maths Chapter 9 Circles is a valuable resource for students who want to gain a sound knowledge in logical thinking and problem solving. It provides students with a clear and concise explanation of the concepts, as well as a large number of solved and unsolved problems. Students can download the solutions for free from the official website, which makes it a convenient and affordable resource. In addition to NCERT Solutions for Class 9 Maths Chapter 9 Circles, Vedantu also offers NCERT Solutions for Class 9 Science and CBSE Solutions for all subjects. These solutions are up-to-date and are sure to help students in their academic journey.
Related Study Materials for Class 9 Maths Chapter 9 Circles
Chapter-wise Links for Class 9 Maths Notes
Related Important Links for Maths Class 9
Along with this, students can also download additional study materials provided by Vedantu for Maths Class 9–
FAQs on Circles Class 9 Notes CBSE Maths Chapter 9 (Free PDF Download)
1. What are the key concepts covered in the Class 9 Circles revision notes?
The revision notes for Class 9 Maths Chapter 9 Circles include core concepts like the definition of a circle, properties of chords, diameters, radii, arcs, sectors, and segments, and important theorems such as angles subtended by chords and arcs, properties of cyclic quadrilaterals, and equality of chords and arcs. The notes focus on the relationships between these properties and provide concise summaries for easy revision.
2. How do revision notes help in quick preparation for the Circles chapter in Class 9 Maths?
Revision notes are designed for efficient last-minute review. They consolidate all the main formulas, definitions, and theorems from the Circles chapter into short, organized summaries. This allows students to recap important points quickly before exams and focus on the most test-relevant areas.
3. What is the relationship between a chord and its distance from the centre of a circle, as highlighted in revision notes?
The revision notes explain that equal chords of a circle are equidistant from the centre. Conversely, chords that are equidistant from the centre are equal in length. This relationship helps students solve problems involving chords and their placement within the circle.
4. How do the theorems about angles in circles support problem-solving in Chapter 9?
The revision notes summarize theorems like “the angle subtended by an arc at the centre is twice the angle at the circumference” and “angles in the same segment are equal”. These theorems are essential for solving questions involving measurements of angles within different parts of the circle.
5. Why is it important to understand the concept of cyclic quadrilaterals in Class 9 Circles?
Understanding cyclic quadrilaterals is important because many exam problems involve identifying such quadrilaterals and applying the property that the sum of opposite angles is 180°. This concept connects circles with quadrilaterals and broadens your problem-solving ability in geometry.
6. How should students use revision notes to build connections between different theorems in circles?
Students should review the sequence in which theorems are derived and understand their logical relationships. For example, the converse of a theorem is often tested, so recognizing how one property leads to another strengthens concept retention and application in varied questions.
7. What misconceptions should students avoid when revising the Circles chapter?
Common misconceptions include
- Confusing the difference between radius and diameter
- Assuming every quadrilateral inscribed in a circle is cyclic without checking the angle property
- Misapplying theorems about arcs and chords without noting the required conditions (like ‘not a diameter’ or ‘equal arcs’)
8. How can concept maps or summary tables aid revision for Circles Class 9?
Concept maps or tables in revision notes allow students to visually organize relationships between definitions, theorems, and properties. This helps in quick recall and clarifies how topics such as chords, arcs, and cyclic quadrilaterals are interconnected within the chapter.
9. What is the best order to revise Circles Class 9 to maximize understanding before exams?
Start with the basic definitions (circle, radius, chord, diameter), then move to properties of chords and their theorems, followed by theorems about arcs and angles. Finally, revise cyclic quadrilaterals and their properties. This logical order mirrors how concepts build upon each other in the NCERT syllabus, ensuring you establish a strong foundation for solving complex questions.
10. What types of questions from Circles commonly appear in Class 9 exams, as per revision notes focus?
Exams typically include
- Statements and proofs of key theorems
- Application-based problems involving angles, chords, and cyclic quadrilaterals
- Short concept-based questions on definitions and properties
- Diagram-based problems where students must label or identify properties
